MOZA RACING R16 WHEEL BASE (16 Nm)

MOZA
mozar16G
$999.00
Size Guide
$999.00
Terms & conditions

Arrive in August, preorder 5% off. Free shipping.

16 N·m of Torque from a Direct Drive Servo Motor

With 16Nm of torque on tap the R16 can lay down an ultra-wide torque range that accurately reproduces the dynamic steering characteristics of top racing cars from F1 to IndyCar. Feel the road through the steering wheel.

Beauty is Power

Inspired by supercars, the R16 has a 3D sculpted body and two-color automotive paint finish. It’s the Perfect Fusion of Design and Power.

All Aluminum Alloy Body

Enhancing the realism the R16 is made of aircraft-grade aluminum alloy. Giving the driver the right weight and feel.

Ultra Low Static Torque

An optimized motor design that offers practically zero torque ripple and cogging. The R16 can smoothly recreate a wide band of precision steering wheel feedback. From the feeling of hard braking, to the tires riding the curb around a corner.

262,144 Points of Resolution

The encoder of the R16 has 262,144 points of resolution. Giving the R16 exceptional ability to understand the position of the wheel to seamlessly reproduce the feeling of racing.

Zero Latency Wireless Technology

Wirelessly transmit data and power between the steering wheel and the base.

Specs


Applicable Platform

PC

Driving type

Direct Drive

Maximum Turning Angle

Limitless

Cover

Aluminum

Color

Orange+Golden/Black

Maximum Torque

16 N·m

Maximum Power

360W

Input voltage

110V~220V AC —>36V DC

Encoder Resolution

262144ppr

USB Refresh Rate

1000Hz

Indicator

YES

Quick Release

Customized Quick Release

Cooling

NONE

Mode Button

NONE

Interface

Power Supply, Data, General Interface

Accessories

Instructions,Power Supply,USB Cable,Warranty Card,Screw

Mounting

4-Hole Pattern on the Bottom, Side Mounting Support with Special BRKT

Mounting Bracket

Bottom Angle Adjustment Bracket/Side Fixing Bracket

Table Clamp

Optional

Side Mounting

YES

Emergency Stop

Optional

Firmware Update

YES

L x W x H

327mm x 170mm x 130mm

Mass

8.9kg

APP Function

YES

Shifting Indicator Light

YES
